| Camera Specification |
|
| Sensor type | 1/2.8" progressive scan CMOS sensor |
| Lux Level(illumination) | Color: 0.002Lux@ (F1.6, ACG ON), B/W: 0Lux with IR |
| Shutter speed | Auto/Manual, 1s ~ 1/100,000s |
| AGC | Yes |
| Lens | 2.8MM fixed focus |
| Focus control | N.A |
| ICR | Mech. ICR |
| IR wave length | N.A |
| IR distance | up to 30 Meter |
| IR function | Smart IR, ICR Dual Filter, IR LED power adjustable |
| Compression/Video/Audio |
|
| Video compression | N.A |
| Video resolution | 4MP(2560x1440P)/3MP(2304x1296P)/2MP(1920x1080P)/1.3MP(1280x960P)/1MP(1280x720P), 704x576(D1), 704x288(2CIF), 352x288(CIF), 640x360 |
| H.264/H.264+ Profile | Main, High, Baseline |
| Main stream | 4MP(2560x1440P)/3MP(2304x1296P)/2MP(1920x1080P)/1.3MP(1280x960P)/1MP(1280x720P) |
| Second stream | 704x576(D1), 704x288(2CIF), 352x288(CIF), 640x360 |
| Third stream | N.A |
| Record & Live frame rate | 25fps at 4MP/3MP/2MP/1.3MP/1MP, 15fps at second stream |
| Bitrate control | VBR, CBR, I-Frame interval |
| Bit Rate | 32Kbps ~ 6Mbps |
| Audio compression & bitrate | Yes |
| Video Analysis |
|
| Intelligent video analysis | Tripwire, Perimeter |
| Perimeter detection mode | Yes |
| Intelligent alarm | Advanced motion detection, Recognize only persons from all the moving objects |
| Alarm & IVA trigger | Yes |
| Corridor control | N.A |
| Region of Interest(ROI) | N.A |
| Advanced warning | N.A |
| Smart Functions |
|
| Intelligent alarm | Advanced motion detection, Recognize only persons from all the moving objects |
| Intelligent codec | 256kbps for 1080P video stream, 1GB storage for 24 hours recording |
| Intelligent image | Advanced algorithm, Identifies persons clearly |
| Camera Functions |
|
| WDR | 120dB, Auto/Manual adjustable |
| Day/Night | Auto(Outside/Inside), Color, B/W |
| Digital noise reduction | 3DNR (Close/Ordinary/Expert) |
| Light compensation | BLC Off/On, 1 area, Customize design, HLC Off/On adjustable |
| White balance | Auto/Manual/Lock/Nature/Sunshine/Day Light/Warm light |
| Other functions | Smart defog control, EIS(Image Stabilizer), Flip control, Motion detection, Privacy masking |
| Image control | Brightness, Contrast, Sharpness, Saturation |
| OSD display | 16x16, 32x32, 48x48, 64x64, adaptable size, letters @ Time/Date/Week/Character/PTZ angle, total 3 regions |
| Alarm alert | On-screen alerts/Link out/FTP upload, PTZ trigger/E-MAIL/Pre-Post record(through NVR) |
| Network, Storage, Interface |
|
| Protocol | TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet |
| Pre & Post recording | Pre : 5 to 15sec, Post : 10 to 60 sec |
| Storage function | ANR |
| Network storage | FTP(pre & post upload) |
| LAN port | 1x Port RJ-45, 10M/100M ethernet |
| Storage | Micro SD/SDHC/SDXC slot(512Gb) |
| Two-Way Intercom | N.A |
| Audio | Built-in MIC |
| Alarm | N.A |
| Video output | N.A |
| USB | N.A |
| Other ports | N.A |
| Software Support |
|
| Onvif | Yes, Profile S |
| CMS software | iCRYS series, up to 256CH(IP+NVR+Matrix) |
| 3rd Party VMS/NVR /CMS | Onvif/SDK |
| Mobile | Cloud support Android /iOS through NVR |
| User login | 8 User / 4 level of rights, Simultaneous login ≤7 user client |
| Snap shot management | Schedule, Link with FTP or Email |
| Encryption | Off/AES |
| General |
|
| Power supply | DC 12V ±15% & PoE (802.3af) |
| Power consumption | <3W @ IR Off, <6W @ IR ON |
| Voltage protection | TVS 6000V, Lightning/Surge 2000V(power) 1000V(RJ45) |
| IP & Vandal protection | IP66 |
| Reset switch | N.A |
| Operating temp. & humidity | -30°C ~ 60°C & 0% ~ 95% RH |
| Enclosure | 3 Axis rotation dome, Metal dome |
| Weight (g) & Dimension | <0.4KG camera, Ø 116mm(D) X 84mm(H) |
