AP-MC210
10 Zone Intelligent PA cum Paging Controller
Categories:
- Cost effective advanced public address system intelligent controller
- PA controller single system included weekly timer, paging & speaker selector, Mp3 player, Integration with fire alarm, voice evacuation and power...
- Cost effective advanced public address system intelligent controller
- PA controller single system included weekly timer, paging & speaker selector, Mp3 player, Integration with fire alarm, voice evacuation and power sequencer
- 1 timer, 1 monitor, 10 zone speaker selector, 6CH power sequencer and Mp3 player
- Master controller supports 10 zones and Expandable up to 80 zones(optional 160 zones)
- Announcement in Neighbor or All zones, When receive signal, automatically trigger alarm
- Different modes of broadcast like random, repeat and circle
- Priority broadcast control for auto BGM and manual
- Full functional keypad to easy and fast access for Paging, Priority and BGM
- High power handling capacity up to 5KW
- Long communication distance up to 1KM for paging devices
- Ideally for school, shopping mall, warehouse, hotel and many more
- Power off memory function
- 19” Ready rack mount installation design
| Specifications | |
| 100V Input | Integrated Terminal 5 Channels |
| EMC Input and Output | Integrated Terminal Block, 0V(Short Circuit) Industrial Standard |
| Amplifier Input and Output | 0.5W |
| Indication Method | 192x64 LCD display |
| Audio Output | 1KΩ 0.775V Unbalance(6.35 RC), 0V(Short Circuit) Industrial Standard |
| Function Button | Light touch buttons, MP3 control, 1 backup switch, 10zones, all zones, 1 music or paging, menu button, Power |
| Monitor Volume Attenuator | 24 hours(hour-minutes-seconds) weekly |
| Time Mode | Total 5pcs(4 normal programs, 1EMC) |
| Program Quantity | Total 512 Steps, 1 day 200 Steps |
| Program Steps | RS422 |
| Communication Protocols | RS485 and RS232 |
| Communication Port | Two RJ45 ports for remote Microphone, one RS232 port for PC |
| Communication Speed | 4800bps |
| MP3 Frequency Response | 20Hz~20KHz/ 1dB |
| Mp3 Store Format | Compatible FAT12, FAT16, FAT32 |
| Power Input | 200-240V AC, Fuse Protection |
| Power Consumption | <15W |
| Mount | 2U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 89(H) x 483(W) x 303(D) mm, <7Kg |
